SKYLINE Automatic guillotine glazing — a motorized vertical-opening glazing system controlled via button, remote control, tablet, or smartphone. Ideal for restaurants, cafés, office buildings, and other public spaces, it provides space flexibility and user convenience

Control – remote control (Somfy)
Integration – compatible with smart home systems
Drive system – belt / chain
Glazing – 12 mm tempered glass / 20 mm safety insulated glass unit

Top and bottom sash parking
Fully sealed system
Provides excellent sound and thermal insulation
Profiles with brush seals
No visible elements, bolts, or fasteners

• Maximum structure width: 4 500 mm
• Maximum structure height: 4 500 mm
• Maximum number of sashes: 4
• Aluminum thickness: 3.5 mm – 4.5 mm

STRUCTURE DESCRIPTION

The structure consists of an aluminum frame, two tracks, sashes, and a motor housing

Material: Aluminum
Drive system: Chain
Motor: Somfy (France)
Fully sealed system (certified and tested)

• Aluminum thickness: 3.5 mm – 4.5 mm
• Glass unit infill: 20 mm insulated glazing
• Maximum width of the structure: 4500 mm
• Maximum height of the structure: 4500 mm
• Maximum number of panels: 5

Panel parking:

• Top panel parking
• Bottom panel parking

Technical Specifications of the Guillotine Glazing System
For 20 mm Insulated Glass Units

The structure consists of an aluminum frame, two tracks, sashes, and a motor housing

Material: Aluminum
Drive system: Belt
Motor: Somfy (France)
Fully sealed system (certified and tested)

• Aluminum thickness: 3.5 mm – 4.5 mm
• Glass unit infill: 12 mm insulated glazing
• Maximum width of the structure: 4500 mm
• Maximum height of the structure: 4500 mm
• Maximum number of panels: 5

Panel parking:

• Top panel parking
• Bottom panel parking

Technical Specifications of the Guillotine Glazing System
For 12 mm Insulated Glass Units

Depending on the project, client preferences, and installation conditions, the SKYLINE Q1 automatic guillotine glazing system can be implemented in various configurations and modifications

By number of panels:
– 2 panels
– 3 panels
– 4 panels

By parking option:
– With top panel parking
– With bottom panel parking

By installation type:
– In-wall installation
– Floor-recessed system
– Ceiling-recessed system

CONSTRUCTION OPTIONS

Additionally, it is possible to install:

• Lighting
• Heaters
• Audio systems
• Fans
• Retractable TV screens

This structure supports integration with the "Smart Home" system, allowing for automated control through digital applications. With the TAHOMA app, which manages devices equipped with a SOMFY RTS motor, you can control the system directly from your smartphone or tablet, ensuring maximum convenience and control at any time

ADDITIONAL OPTIONS
