SKYTECH Retractable Glass Roof
SKYTECH – motorized sliding glass roof. The system consists of load-bearing beams and a structural frame.
- 💧 Integrated drainage system
- 🪟 36 mm double-glazed units with tempered glass
- 🏗️ Installation on special metal supports or its own frame
- 📐 Adjustable tilt angle: 6–8°
- ⚙️ Becker motor (Germany)
- 🔗 Chain drive
🎛️ Control – remote (handheld remote)
📱 Compatible with smart home systems
🛡️ Fully sealed system
STRUCTURE DESCRIPTION
Material: aluminum
Drive: chain mechanism
Glazing: 36 mm safety double-glazed unit
Seals between panels
Load capacity: 180–220 kg/m²
(depending on construction size)
Adjustable tilt angle: 6–8°
Integrated drainage system
TECHNICAL SPECIFICATIONS
Main system components
RECOMMENDED RETAIL PRICE
for the finished structure
SKYTECH
Projection: 8000 mm
Width: 8000 mm
Height: 3000 mm
LED lighting – Samsung
Motor – Becker (Germany)
Somfy 1-channel remote control
The electric motor drives the glass panels, each of which can move independently. The design allows simultaneous opening of 2/3 of the sections. The sliding glass panel system opens and glides smoothly and silently. With a single press of the remote control, the roof can be fully opened, offering an unobstructed view of the sky, free from bulky structures and frames.
The system is available in three configurations:
- 2-panel (maximum projection up to 5 000 mm)
- 3-panel (projection up to 7 500 mm)
- 4-panel (projection up to 8 000 mm)
Maximum width of a single panel is 1 250 mm
CONSTRUCTION OPTIONS
SKYTECH provides enhanced sealing of double-glazed units along with excellent sound and thermal insulation. Neither precipitation nor external noise will interfere with peaceful rest and comfortable living inside the space. The SKYTECH automatic glass roof is equipped with a well-designed drainage system featuring both external and internal gutters that protect the interior from moisture intrusion.
This structural concept, combined with the precise engineering of all components, achieves two key goals:
– to deliver the comfort and protection of a solid roof structure
– while offering natural light, ventilation, and a sense of openness, just like a pergola or veranda
Drainage system
Integration Options
Depending on project requirements, client preferences, and installation specifics, the SKYTECH system can be seamlessly combined with other solutions from ALUMINANTE. This allows you to create a project in a unified architectural style and source all essential components from one trusted supplier
ALUMINANTE products compatible with the SKYTECH automatic roof:
– Orizzonte, Orizzonte Thermo, Spazio, Aspetto glazing systems
– Skyline vertical sliding (guillotine) glazing
– Agio lift-and-slide doors
– Piega folding doors
– Vito Zip and Dazzoni sun-shading systems
Additionally, it is possible to install:
- Lighting
- Heaters
- Audio systems
- Fans
- Retractable TV screens
This structure supports integration with the "Smart Home" system, allowing for automated control through digital applications. With the Somfy motor, you can control the system directly from your smartphone or tablet, ensuring maximum convenience and control at any time
ADDITIONAL OPTIONS
SKYTECH retractable glass roof
SKYTECH is a retractable glass roof for terraces, winter gardens and restaurants, also sold as a motorized glass roof. In Europe the same product is known as a sliding glass roof or an opening glass roof. Panels of 36 mm double glazing slide on a chain drive powered by a Becker motor, and part of the roof opens at the press of a remote.
Closed, the roof is sealed and insulated against rain, cold and street noise. Open, the guests sit under the sky and the room keeps its glass walls.
Technical specifications
| Parameter | Value |
|---|---|
| Maximum projection, one module | 8 000 mm |
| Panel size | up to 1 250 mm wide, up to 2 500 mm projection |
| Glazing | 36 mm safety double glazed unit |
| Roof pitch | 6° to 8° |
| Weight load | 180 to 220 kg/m², depending on the size of the structure |
| Drive | Becker chain drive, Germany |
| Control | handheld remote, smart home ready |
| Drainage | internal and external gutters |
| Finish | powder coating in any RAL color |
How the roof opens
The panels run on rails inside the beams and stack over each other as the roof opens, so nothing folds and nothing hangs. The drive is a chain, not a belt, which is what lets the system move 36 mm glass without a visible gantry.
A closed roof is a sealed one: gaskets between the panels and gutters inside the frame take the water to the posts. That is the difference from a canopy, and the reason SKYTECH is used over restaurant terraces that trade in winter.
SKYTECH: frequently asked questions
How much of the roof opens?
It depends on the number of panels in the module. Each panel slides over its neighbor, so the more panels there are, the larger the open part becomes.
Is the roof insulated?
Yes. The glazing is a 36 mm double glazed unit, and the panels close onto gaskets, so the room holds heat in winter.
What is the largest module?
Projection up to 8 000 mm per module, with panels up to 1 250 mm wide. Wider terraces are covered by several modules side by side.
SKYTECH or PAVILION?
SKYTECH is built for terrace scale, PAVILION for large spans up to 26 by 60 m over pools, atriums and sports courts.
Can the sides be glazed?
Yes. SKYLINE guillotine glazing and ORIZZONTE sliding glazing close the perimeter under the roof.
