Motorized louvered pergola ACURA Q27 Twist
ACURA Q27 Twist Pergola – Advanced Terrace System
The ACURA Q27 Twist pergola is a modern terrace system designed to protect open spaces of cafes, bars, restaurants, hotels, and private residences from sun, rain, and wind.
- Opening Type – Automatic rotating louvers
- Quick Installation – Assembles in just 4 hours
- Control – Remote-controlled (handheld remote)
- Smart Home Integration – Compatible with home automation systems
- Fully Sealed System – Ensures complete weather protection
Technical Specifications:
- Maximum Projection per Module – 7,000 mm
- Maximum Width per Module – 4,000 mm
- Snow Load Capacity – 220-250 kg/m²
STRUCTURE DESCRIPTION
Fill in the details
Built-in drainage system for water runoff
Seals between the louvers
Louver – Hilam 185 mm
Post Size – 150 x 150 mm
Panel Profile Thickness – 34 mm
The system includes one row of Samsung LED lighting
Motor – Somfy (France)
TECHNICAL SPECIFICATIONS
PROFILES OF THE SYSTEM
Fill in the details
RECOMMENDED RETAIL PRICE for the finished structure
ACURA Q27 Twist
Freestanding structure
Projection: 6000 mm
Width: 4000 mm
Height: 3000 mm
LED lighting – Samsung
Motor – Somfy (France)
Somfy 1-channel remote control
Projection: 6000 mm
Width: 4000 mm
Height: 3000 mm
LED lighting – Samsung
Motor – Somfy (France)
Somfy 1-channel remote control
$
16 600
Fill in the details
WHOLESALE PRICE
for the profile
ACURA Q27 Twist
CONTAINER (25 STRUCTURES WITH PROFILES)
Projection: 6000 mm
Width: 4000 mm
Height: 3000 m
LED lighting – Samsung
Motor – Somfy (France)
Somfy 1-channel remote control
Projection: 6000 mm
Width: 4000 mm
Height: 3000 m
LED lighting – Samsung
Motor – Somfy (France)
Somfy 1-channel remote control
$
250 000
The aluminum louvers rotate 90 degrees, providing ventilation and optimal airflow and light. When closed, they act as a shield against external factors such as precipitation, solar radiation, cold air, debris, insects, and noise
The ACURA Twist Q27 bioclimatic pergola uses Deferental Tech technology – a type of opening where the panel rotates deferentially along the circumference, allowing it to press against the surface and create a sealed roof
TECHNOLOGY Deferental Tech
Depending on the project, customer preferences, and installation requirements, the system can be:
- Freestanding
- Wall-mounted
- Suspended
- Frame-mounted without posts
CONSTRUCTION OPTIONS
INTEGRATION OPTIONS
Depending on the project requirements, client preferences, and installation details, the ACURA Q27 Twist system can be successfully integrated with other solutions from ALUMINANTE. This allows for a cohesive design and the ability to purchase all necessary products from a single reliable supplier
Products from ALUMINANTE compatible with ACURA Q27 Twist:
- Orizzonte, Orizzonte Thermo, Spazio, Aspetto slide glazing
- Skyline automatic guillotine glazing
- Agio lift-and-slide doors
- Piega folding doors
- Vito Zip automatic sun protection system
Additionally, it is possible to install:
- Lighting
- Heaters
- Audio systems
- Fans
- Retractable TV screens
This structure supports integration with the "Smart Home" system, allowing for automated control through digital applications. With the Somfy motor, you can control the system directly from your smartphone or tablet, ensuring maximum convenience and control at any time
ADDITIONAL OPTIONS
Versatility of ACURA Q27
New development: the ACURA Q27 frame can integrate various roof options:
- Automatic and static
- Glass with warm or cold profiles
- Aluminum louvered pergolas
- Sun protection (automatic or static) with Serge Ferrari fabric
- Solar panels
Yes, you understood correctly! One frame allows for the integration of any roof option, ensuring maximum flexibility and convenience
ONE FRAME - SEVERAL ROOF OPTIONS
Pay attention when choosing pergolas
Disadvantages of the structures
(01)
Frame
Weak load-bearing structure
Additional reinforcement with brackets due to instability. Weak load-bearing capacity
Weak structural stability – leads to deflections and sagging, reducing the durability of the structure
Thin metal – high susceptibility to corrosion and deformation
Quality standard A L U M I N A N T E
(01)
FRAME
Solid, durable structure
Monolithic posts – no need for additional reinforcements, increased reliability and durability
Thick-walled anodized aluminum T6063: Resistance to loads, corrosion-free. Complies with ISO 9001 standards
Hidden fastening elements – aesthetic appearance and protection from external factors
Disadvantages of the structures
(02)
Columns
The column is assembled from several profiles
The column is assembled from several profiles instead of a solid structure due to weak stability and low-quality aluminum
Weak fixation of elements: multiple screw connections instead of a solid system
Exposed fasteners – disrupt aesthetics and reduce protection from external factors
Quality standard A L U M I N A N T E
(02)
Columns
Solid, durable structure
Solid fastening system – minimal connections and no weak points, ensuring optimal static load and high-quality aluminum
Reliable sealed fastenings – no unnecessary holes, preventing corrosion and leaks
Modern design: Perfect assembly, precision of details, and a premium appearance without unnecessary elements
Pay attention when choosing pergolas
Disadvantages of the structures
(03)
Sealing
Gaps in the frame
Leaks and gaps. Rain easily penetrates inside, damaging furniture, equipment, and interior. Be prepared for losses!
Hidden costs – moisture causes corrosion. Saving money on the purchase leads to ongoing expenses
Insects and dirt – gaps allow mosquitoes, dust, and debris to enter. Guests on the terrace or restaurant clients are unlikely to appreciate such a "surprise"
quality standard A L U M I N A N T E
(03)
Sealing
Tight fitting of elements
The patented system of additional seals completely eliminates leaks, providing protection from rain, snow, and wind
Durability – the reliable system lasts for decades without the need for repairs or part replacements
The tight fitting of elements prevents dust, insects, and outdoor debris from entering. Your terrace remains fresh and cozy
Pay attention when choosing pergolas
Disadvantages of the structures
(04)
Exposed mechanism
Short lifespan and unsafe
Exposed mechanism – susceptible to dirt, moisture, and dust, which reduces its lifespan
Unaesthetic design – rough and untidy assembly
Risk of short circuit: Exposed wiring and moisture pose a direct threat of fire or equipment failure
Quality standard A L U M I N A N T E
(04)
Closed mechanism
Long lifespan and safe
Closed mechanism: Fully protected from moisture, dust, and dirt, significantly increasing its lifespan
Modern design: Perfect assembly, precise details, and a premium appearance without unnecessary elements
No external fasteners – We do not use screws in load-bearing elements, eliminating the risk of corrosion, leaks and loss of strength
Disadvantages of the structures
(05)
Low-quality motors
Exposed wires
Visible wires: Diminish the appearance and are vulnerable to external impacts
Motors may fail to synchronize, make noise, and break down at the most inconvenient time, such as during rain
Low-quality Chinese motors, two of which are often required for operation, as one cannot handle the load
Quality standard A L U M I N A N T E
(05)
European motors
Safe wiring
Safe wiring: No risk of short circuits – all electrical components are concealed within the housing, preventing contact with moisture
In A L U M I N A N T E systems, powerful SOMFY motors are reliable, quiet, synchronize seamlessly, and operate without failure even in challenging weather conditions
We use only European SOMFY motors, which handle any load and operate flawlessly under all conditions
Pay attention when choosing pergolas
Structural Disadvantages
(06)
Budget Coating
Corrosion and Paint Peeling
Budget Coating: Prone to Corrosion and Peeling
Hidden costs – Moisture, leaks, and corrosion can lead to furniture repairs or even a complete pergola replacement. What seems like a budget-friendly solution may require additional expenses for modifications, replacement of low-quality components, and repairs
White or rusty deposits and loss of aesthetic appeal – common issues with cheap coatings
Quality Standard A L U M I N A N T E
(06)
AkzoNobel Coating
High-Quality Coating
AkzoNobel coatings used by Aluminante are corrosion-resistant, retaining their color and appearance for many years
Elegant minimalism and a cohesive style – all products are designed within a unified concept, and thanks to impeccable sealing, no silicone or screws are needed
Our coating provides reliable protection against external influences, does not peel, flake and develop deposits
Structural Disadvantages
(07)
Messy joints
Silicone and screws in visible areas
Messy joints and gaps sealed with silicone and screws lead to the risk of corrosion and leakage. Short lifespan and high risk of damage
Lack of individual approach – Mass-market solutions do not consider the unique aspects of your project, which may result in operational inconveniences
Service and spare parts Issues – if the structure breaks down, finding original components or maintenance service can be challenging
Quality Standard A L U M I N A N T E
(07)
Wide range
High precision profiles
Reliable Aluminante systems, European components, and proven mechanisms are designed to operate for decades without repairs or part replacements
Wide range – pergolas, windows, guillotines, zip screens, sliding systems – all in one place
We tailor solutions for specific projects, considering all client preferences, with no visible wires, messy connections, or rough assembly
Structural Disadvantages
(08)
Various suppliers, lack of technical support
Lack of quality guarantee – resellers often work with various suppliers, making it impossible to predict which materials and components will be used
Lack of technical support – many resellers simply sell the product without providing design solutions, visualizations, or installation assistance
Incompatible elements – different manufacturers may use varying standards, causing structures to not always fit together perfectly
Absence of warranty
Quality Standard A L U M I N A N T E
(08)
Quality guarantee
Reliable partner, project support
Reliable partner – stable deliveries, quality control, and favorable terms for long-term cooperation
Supervisor installation and support – we assist with installation and technical issues to ensure everything works flawlessly
Individual approach – we develop the project, create visualizations, and select solutions tailored to specific projects, considering all client preferences and property characteristics
If you are interested in our products, as well as on cooperation issues:
|
Motorized louvered pergola
ACURA Q27 Twist in short
Q27 Twist is a motorized louvered pergola for villas, cafés and hotel terraces. Its 185 mm aluminum louvers turn 90 degrees to let in air and light, and close into a sealed roof. In the UK and Europe the same system is sold as an adjustable louvre roof.
Modules reach 7 000 by 4 000 mm and carry 220 to 250 kg/m² of snow. The roof runs on a Somfy drive, from a handheld remote or a smart home system.
Sealing
Differential Tech: how the roof seals
A louver roof leaks where the blades meet. Differential Tech is our answer to that: each louver turns along its circumference and presses against the seal of the next one, instead of simply resting on it.
The result is a closed roof that keeps rain, wind and noise out, with the water taken away through gutters inside the beams and down the posts.
Specifications
Technical specifications
| Parameter | Value |
|---|---|
| Louver | 185 mm |
| Rotation | 90°, sealed by Differential Tech |
| Maximum module | 7 000 × 4 000 mm |
| Snow load | 220 to 250 kg/m² |
| Post | 150 × 150 mm |
| Panel profile | 34 mm |
| Motor | Somfy, remote control, smart home ready |
| Lighting | Samsung LED, one row in the beam |
| Assembly | about 4 hours per module on a prepared base |
Configurations
Construction options
See completed bioclimatic pergola projects
Freestanding
Four or more posts, anywhere on a terrace or in a garden.
Wall-mounted
Fixed to the facade on one side, posts on the other.
Suspended
Hung from the building structure, no posts at the front.
Modules in a row
Several modules side by side over a long terrace.
Complete terrace
Screens, glazing and light
One row of Samsung LED sits in the beam. The sides of the pergola close with VITO ZIP screens, SKYLINE guillotine glazing or ORIZZONTE sliding glazing.
FAQ
ACURA Q27 Twist: frequently asked questions
Twist or Q25 Premium?
Twist rotates the louvers only, up to 7 by 4 m per module. Q25 Premium rotates and slides them, opens 85% of the roof and reaches 9 by 4 m.
Is the roof watertight?
Yes, with the louvers closed. Differential Tech presses each louver against the seal of the next one, and the gutters are built into the frame.
Can Twist be wall-mounted?
Yes. Freestanding, wall-mounted and suspended versions are all standard.
What snow load does it carry?
220 to 250 kg/m², depending on the spans.
What if I do not need a motor?
The static versions are Q27 Statico, a closed sealed roof, and Q27 Lamella, fixed open for shade.
